Q235 Single Inlet Forward CFB Boiler Industrial Centrifugal Fans
Introduction Of Centrifugal Fan
The 4-09 series large-flow centrifugal fan is the earliest used fan in China, and it is also the most commonly used fan.
The impeller is annealed to eliminate the internal stress generated during welding, ensuring that the impeller does not undergo creep and cracks.
Fan systems with impeller diameters less than 1400 mm at normal temperature do not require additional bearing cooling devices, reducing users’ investment and maintenance.
It has large flow and low noise, more use in building ventilation, ventilation and drying of materials, air purification and industrial waste gas treatment, industrial dust collectors, air purification and discharge in hazardous working environments(Paper production line, electrolytic aluminum production line, textile factory...). Blasting of boilers and brick kilns, transport of various gases, transport of granules/powders/debris/fiber materials, etc.
Technical data
| series | model | Rotation Speed
(r/min) | Total Pressure
(Pa) | Air Capacity
(m³/h) | Power
(kW) |
| 4-09 | 7C | 710 ~ 1800 | 233 ~ 2406 | 4939～24038 | 1.5 ~ 15 |
| 8C | 630 ~ 1800 | 240 ~ 3150 | 6542～ 35882 | 1.5 ~ 37 |
| 10C | 520 ~ 1300 | 258 ~ 2551 | 10931～50807 | 3 ~ 37 |
| 12C | 420 ~ 1170 | 242 ~ 2980 | 15256 ~ 79015 | 4 ~ 75 |
| 1040 | 2349～1493 | 37778～70236 | 55 |
Product Advantages
The airflow channel and the impeller are optimized several times, which is more efficient and energy-saving than ordinary large-flow fans.
Made of high quality carbon steel, Stainless steel or other metal materials can also be used according to user requirements.
After the production is completed, all products are tested for running and vibration values for reliable operation.
Installation is simple and does not require the support of professional technicians.
FAQ
1. What parameters need to be provided when you design the Heat Dissipation Power Plant Blower Fan?
Answers: Air flow, total pressure or static pressure, inlet temperature, local voltage and frequency, Altitude etc.
If there is flammable and explosive gas, or big dust loading in the medium, please also inform the designer.
2. How about your company’s pre-sales service and after-sales service?
Answers: Before our cooperation, we have the professional technical team to help you make the technical solution according to your working condition, to make sure the centrifugal fan efficiency operation.
After sales service, we will offer 12 months’ repairing service, and provide lifelong follow-up services. Besides, our engineers are available for going abroad to offer the repairing service.
3. Does your company have qualifications?
Answers: SIMO Blower has obtained ISO 9001-2008, CE, TUV certifications and so on.
